FEATURES
- Extend optical and coaxial digital audio signals up to a distance of 300m (48kHz), 150m (96kHz) or 100m (192kHZ) over a single CAT cable
- Built-in DAC (Digital to Analog Converter) converts either optical or coaxial digital (selectable) to analog stereo left/right audio output (PCM only) Optical and coaxial digital signal can be distributed at the same time Support sample rates 32 kHz, 44.1 kHz, 48 kHz, 96 kHz and 192 kHz up to 24-bit resolution
- Support LPCM, DTS, Dolby Digital and Dolby Digital Plus when used as a straight digital in/digital out extender
- Support one-way POC function. The transmitter is powered on by the receiver through the CAT cable
- Plug-and-play
- Small compact size
- Ultra-low jitter and high-fidelity design
Specification
CONNECTION DIAGRAM
DOWNLOAD
